Home > Stainless Steel > Stainless Steel 316H Heat Exchanger Tubing
Since you’re sourcing top-tier industrial components, Lathief Pipes in Safat, Kuwait stands as your reliable partner for Stainless Steel 316H heat exchanger tubing. We specialize in providing tubing that delivers exceptional performance under intense conditions, where failure isn’t an option. Our commitment is to equip your critical operations with material renowned for its superior strength and corrosion resistance, ensuring your systems run smoothly and efficiently.
This tubing is crafted from a durable austenitic chromium-nickel steel, with key additions like molybdenum to significantly boost its resistance to corrosion. The ‘H’ designation indicates a specific mid-range carbon content, which gives the material enhanced tensile and yield strengths, particularly important when exposed to high temperatures. This careful composition ensures the tubing maintains its structural integrity and performance even under the stress of demanding thermal cycles.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316H |
| C | 0.10 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.89 min |
| Element | SS 316H |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Heat Exchanger Tubing from Lathief Pipes and Tubes ensures superior quality and reliability. With expertise in precision manufacturing, Lathief Pipes and Tubes provides 316H tubing that offers exceptional strength and corrosion resistance, especially in high-temperature and corrosive environments. Their products meet stringent industry standards, ensuring long-lasting performance in demanding applications. Additionally, Lathief Pipes and Tubes is known for timely deliveries, excellent customer service, and customized solutions, making them a trusted supplier for industries like chemical processing, power generation, and oil and gas.
Lathief Pipes and Tubes, one of the largest suppliers of Stainless Steel 316H Heat Exchanger Tubing in Safat, Kuwait, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316H Heat Exchanger Tubing to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 316H | 1.4401 | S31609 | SUS 316H |
You’ll find Stainless Steel 316H Heat Exchanger Tubing widely used in heat exchangers, condensers, boilers, and pressure vessels across the chemical and petrochemical sectors, as well as in oil and gas refineries and power plants. Its outstanding corrosion resistance and ability to handle high temperatures make it a go-to for marine, pharmaceutical, and food processing applications where hygiene and durability are paramount. Moreover, it’s utilized in water treatment plants, desalination facilities, and other high-performance systems that require reliability under thermal stress. This tubing guarantees efficient heat transfer, structural integrity, and long-lasting performance even in the most challenging environments.
